Overview

This training guide enables you to use your introductory modeling skills to create sheet metal models, including wall, bends, notches, and form features. On completion of this course, the student will have acquired the skills to confidently manipulate sheet metal geometry, adjust bend developed lengths, and convert solid parts. Course topics: The sheet metal environment Primary and secondary walls Bend relief Corner relief Regular unbends, back bends, and cuts Notches and punches Bend features Unbending complex geometry Sheet metal forms Documenting a sheet metal part Converting solid parts Sheet metal setup Investigating a sheet metal part Prerequisites: It is recommended to complete the following courses, or have the equivalent Creo Parametric experience: "Creo Parametric 2.0: Introduction to Solid Modeling - Part 1" "Creo Parametric 2.0: Introduction to Solid Modeling - Part 2" "Creo Parametric: Core Update, Wildfire 4.0 to Creo Parametric 2.0"
